Description
Key Features
- Flow Rate Range:
- 0.1–1,200 mL/hr (adjustable in 0.1 mL increments for precision).
- Infusion Modes:
- Continuous, intermittent, or bolus delivery.
- Dose calculation based on patient weight (mL/kg/hr).
- Safety Alarms:
- Occlusion, air-in-line, low battery, empty reservoir, and door-open alerts.
- Battery Backup:
- Rechargeable lithium battery (4–8 hours of runtime).
- Compatibility:
- Works with standard IV sets (e.g., Baxter, Fresenius).
- Supports bag sizes from 50 mL to 1,000 mL.
- LCD Display:
- User-friendly interface with real-time monitoring of volume infused, rate, and time remaining.
Technical Specifications
- Dimensions: ~30 x 15 x 15 cm (compact for bedside or portable use).
- Weight: ~3–4 kg (lightweight for a volumetric pump).
- Power Supply: 100–240V AC (global compatibility).
- Memory Function: Stores infusion history (up to 1,000 events).
Applications
- IV Antibiotics: Prolonged antibiotic therapy.
- Pain Management: Continuous analgesic delivery.
- Hydration/Nutrition: Parenteral fluids or TPN (total parenteral nutrition).
- Blood Transfusions: Controlled delivery of blood products.
- Chemotherapy: Accurate dosing of cytotoxic drugs.
Safety Mechanisms
- Anti-Freeflow Protection: Prevents uncontrolled fluid release during setup.
- Occlusion Pressure Monitoring: Adjustable pressure settings (e.g., low/medium/high).
- Air Bubble Detection: Halts infusion if air is detected in the tubing.
- Password Protection: Restricts unauthorized changes to settings.
Setup and Operation
- Load IV Set: Thread tubing through the peristaltic mechanism.
- Prime Tubing: Remove air bubbles manually.
- Program Parameters: Enter flow rate, volume, and mode.
- Start Infusion: Monitor alarms and patient response.
Maintenance
- Daily: Wipe surfaces with disinfectant; check tubing for wear.
- Monthly: Calibrate per manufacturer guidelines.
- Battery Care: Fully discharge/recharge monthly to extend lifespan.
Key Takeaways
The Infusion Pump is a cost-effective solution for healthcare facilities needing reliable, no-frills fluid delivery. While it lacks the sophistication of premium brands, it performs well for routine IV therapy in resource-limited settings.
